TDFQs Series Double Wing Gate

TDFQs pneumatic double wing gate mainly used for processing industries such as feed, grain, food, oil and chemical, it can be a cut and throttle on pipes.


Features

  It is widely used for process of grain, feed, flour, oil, chemical, metallurgy, etc, low residue

   It is for controlling of materials in and out. Cylinder is adopted to push connection rod to move, easy operation.



■   Two unique turning blades are adopted to open and close, effectively decomposing pressure, not easy to leak, better sealing

■   Small volume, light weight

■  Good adjustment and sealing

■  Simple structure, quick open can close





Model

Effective working area mm2

Work pressure MPa

Valve plate dia. mm

TDFQs30

1/4π300²

0.15—0.9

300

TDFQs50

1/4π500²

0.15—0.9

500

TDFQs70

1/4π700²

0.15—0.9

700



Housing:-3/Q235

Valve plate:-6/Q235

Air cylinder:DELIXI(with self lock)

Solenoid valve: Air Tac
